Artifact Details

Title

Archistrat 4S server

Catalog Number

102756981

Type

Physical Object

Date

1995

Manufacturer

Panda Project, Archistrat Division

Place Manufactured

Boca Raton, Florida, USA

Identifying Numbers

Part number 4826000 Rev3.5 On backplane
Serial number 4S61404003 Printed on tags above and below card cage
Serial number 611000092 On backplane

Dimensions

overall: 24 1/2 in x 15 in x 22 in

Description

Object is a floor standing server is a curved enclosure. The front door lowers to reveal a floppy drive, and several other storage drives. A removable top cover reveals fans, SCSl, modem, printer, keyboard and mouse, and serial connectors. There are also six slots for I/O cards, two of which are empty. There is a phone modem, display card, network card, and a card with two fine-pitched connectors.
A removable rear door reveal a motherboard, and four processor slots, two of which have cards.
At the bottom is a fan, power connector, and switches.
Top cover locks and keys are storedwith unit.

Category

Digital computer/personal computer/desktop

Credit

Gift of Stanford W. Crane, Jr.

Lot Number

X7964.2017
