The Mouse

Prototype Engelbart mouse (replica)

SRI engineer Bill English built the first Engelbart mouse prototype, which used knife-edge wheels and had space for only one button.

The Mouse

Trackballs, light pens, and other clever pointing devices were widespread. Then the mouse was invented. Twice. (Well, at least twice.)

Doug Engelbart reportedly conceived the mouse during a conference lecture in 1961. His first design, in 1963, used rolling wheels inspired by mechanical area-measuring devices called planimeters invented in the 1800s.

Engineers at Germany’s Telefunken also invented a mouse in the mid-1960s. First described in 1968, their version used a rolling ball—essentially a small, upside-down trackball—which became the standard for decades.

Engelbart mouse patent drawings

The word “mouse” does not appear in Engelbart’s patent for the computer pointing device that became ubiquitous within 20 years. The knife-edged wheels each rolled in just one direction, transmitting movement information for that direction. Each slid without turning when the mouse was moved in the other direction.

View Artifact Detail
1 2 3
RKS 100-86 mouse ("Rollkugel")

The Telefunken Rollkugel may have been the first rolling-ball mouse.

View Artifact Detail
1 2 3 4 5
Production-run three-button mouse, serial number 001

By 1968, SRI had provided Doug Engelbart with commercially produced three-button mice to use in his famous “Mother of all Demos.”

View Artifact Detail
Who Named the Mouse?

When asked who named his most famous invention, Doug Engelbart recalled, “No one can remember. It just looked like a mouse with a tail, and we all called it that.” The wire “tail” originally came out under the user’s wrist.

DATAR trackball

Using a ball from the Canadian 5-pin bowling game, this was likely the first trackball. It controlled radar plotters in a computerized multi-ship defense system designed in Canada.

View Artifact Detail
Bill English at the ARC office

Bill English built the original wooden Engelbart mouse prototype. He is seen here working at an SRI ergonomic workstation.

View Artifact Detail
Ergonomic NLS keyboard console

Engelbart commissioned office furniture maker Herman Miller to build special workstations to hold the chording keyset, conventional keyboard and mouse.

View Artifact Detail
1 2
Rolling ball mouse for Alto computer

Bill English moved to Xerox PARC in 1971. His group developed PARC’s first mouse, a rolling-ball design like that of the 1968 Telefunken mouse.

View Artifact Detail
A Menagerie of Mice

The basic idea of the mouse is simple, but there are many variations on the theme. Engineers have experimented with different shapes, numbers of buttons, internal mechanisms, and aesthetics -- as well as with the part of the human body that activates it.

1 2 3 4
Three-button Depraz mouse

Shortly after its founding, Logitech sold this rolling-ball mouse design by André Guignard in the U.S.

View Artifact Detail
1 2 3 4
Multi-button mouse

How many buttons should a mouse have? For 20 years, Apple said “one.” Video-editing system maker Quantel, however, found many buttons helpful for operating its sophisticated systems.

View Artifact Detail
Bili Foot Mouse Programmable Pedal

Foot mouse users include people with hand and arm problems, and people who want to keep their hands on the computer keyboard or other control devices.

View Artifact Detail
1 2 3 4
Jouse Sip Puff mouse system

Users move this joystick with their mouths. Short inhalations and exhalations signal “mouse clicks.”

View Artifact Detail
1 2 3
"Mousetop" mouse cover box

The name “mouse” inevitably led to quirky accessories and packaging.

View Artifact Detail
1 2 3 4
Wooden optical mouse

This wooden mouse combines up-to-date technology with old-world craftsmanship.

View Artifact Detail
1 2 3
Mouse interior mechanism

This is the internal mechanism of a modern rolling-ball mouse, with the ball removed.

View Artifact Detail
