Connections: Local Networks

Robert Metcalfe and David Boggs

As a student, Metcalfe connected computers to the early ARPAnet. He teamed up with Stanford graduate student and radio expert David Boggs to implement Ethernet, and later to collaborate on internetworking.

Connections: Local Networks

Computers had to communicate down the hall, as well as globally. Local area networks (LANs) connect computers that are physically close. They evolved from the early links to peripheral devices such as terminals and printers.

As cheap PCs and local networks became increasingly commonplace in 1980s offices, fierce competition flared among rival standards—with Ethernet eventually dominating.

Ethernet

Invent the “office of the future.” That was the assignment at Xerox’s Palo Alto Research Center (PARC) in 1970. Its research revolved around groundbreaking personal computers called Altos, connected to peripherals and each other through local networks.

How would they connect? ARPANET alumnus Bob Metcalfe provided the answer.

Familiar with ALOHANET, a pioneering digital radio network, Metcalfe realized he could adapt that radio-based model to cables. This simplified the challenge by treating cables as a passive medium, like the air (“ether”) between radio stations. David Boggs and others helped Metcalfe create “Ethernet”.

ALOHAnet: wireless data pioneer

Norm Abramson started ALOHAnet at the University of Hawaii in the early 1970s. The first packet-switched wireless digital network, it inspired Ethernet and is an ancestor of GSM, Wi-Fi, 3G and Bluetooth.

View Artifact Detail
The Xerox Alto

The Alto project was famous for its graphical interface, laser printing and more. But just as central to the Alto vision was networking, from sharing files and printers to connecting with the wider world.

View Artifact Detail
Composite sketch of Ethernet showing "ETHER!"

The Ethernet protocol let a computer send a message whenever the wire was quiet. Every computer received every message, but ignored messages not for it. If two messages collided, they were sent again later.

View Artifact Detail
1 2 3
Alto II Ethernet printed circuit board

This board went inside an Alto computer, and provided the electronics for connecting it to an Ethernet network. PCs needed similar boards a few years later.

View Artifact Detail
Local Area Warfare

Ethernet was a system for establishing local networks—but not the only system.

There were academic systems such as England’s Cambridge Ring. Commercial rivals included IBM’s Token Ring and Datapoint’s ARCNET. These all used a model in which computers circulated “tokens” that controlled which machine could send data. Competition also came from the telecommunications industry, as business telephone systems began adding data capabilities.

In 1979, Ethernet creator Bob Metcalfe left Xerox and co-founded 3Com, successfully convincing Digital Equipment Corporation, Intel, and Xerox to back Ethernet as a standard.

IBM Token Ring diagram

Computers connected in a logical ring circulate a data “token” that gives permission to send data. Some argued that this was fairer or more “deterministic” than Ethernet.

View Artifact Detail
ARCNET cable

ARCNET was a proprietary token-passing network. It used point-to-point cables wired to distribution hubs, unlike Ethernet’s shared cable. This more reliable physical configuration – but not the token-passing -- was adopted for later versions of Ethernet.

View Artifact Detail
LocalTalk local area networking cable

Apple’s 1984 Macintosh was a network-ready personal computer. LocalTalk was its low-cost daisy-chained physical network, transmitting at 230 Kbits/s. AppleTalk protocols communicated with a shared LaserWriter printer. Apple later cancelled plans for a more extensive networked “Macintosh Office.”

View Artifact Detail
1 2
Token Ring patch cable

The clever connectors on Token Ring cables are the same on both ends, so that two identical connectors can plug directly into each other. Having separate “male” and “female” ends was not necessary.

View Artifact Detail
Digital business phone system, Rolm

In the late 1970s and 80s, digital business telephone systems tried to compete with LANs by providing some connectivity for computers. But they were not as flexible or cost-effective.

View Artifact Detail
1 2
AMP Ethernet boring tool

Ethernet transceivers connected to the main cable with a “vampire tap” that pierced the outer jackets and made contact with the center conductor. Since the cable was shared, a poor installation could bring down the network.

View Artifact Detail
